Description

• SpeedyBee F405 Mini BLS 35A 20x20 Stack F405 30x30 Mini Flight Controller, 35A BLHeli_S Mini 4-in-1 3-6S ESC Product Name: SpeedyBee F405 V3 30x30 Flight Controller -MCU: STM32F405; -IMU(Gyro): ICM42688P; -USB Port Type: Type-C; -Barometer: Built-in; -OSD Chip: AT7456E chip; -BLE Bluetooth: Supported Used to hook up with the SpeedyBee App for flight controller and ESC parameter configuration Please make sure the MSP turn on UART four is turned on and set to a baud rate of 115200, otherwise Bluetooth performance aren't obtainable -Wireless FC Firmware Flashing: NOT Supported Please hook up with the Betaflight configurator at the PC to do FC firmeare update; -Wireless Blackbox Dwonload & Analysis: NOT Supported Please hook up with the Betaflight configurator at the PC to do blackbox analysis; -WIFI: Not supported; -DJI Air Unit Connection Way: Direct soldering; -DJI Air Unit Compatibility: Compatible with all DJI Air Units: DJI O3/ RunCam Link/ Caddx Vista/ DJI Air Unit V1 Please use the solder pads<9V, G, T1, R1, G, SUBS(R2)>on the entrance appropriate corner of the flight controller to make a pin-to-pin connection with the solder pads at the DJI Air Unit UART1(T1, R1) is used for OSD and SUBS(R2) is used for DJI Air Unit’s internal SBUS receiver sign enter -Blackbox: 8MB Onboard Flash; -BetaFlight Camera Control Pad: Yes(CC pad on the entrance side); -Current Sensor Input: Supported For SpeedyBee BLS 35A V2 ESC, please set Scale=250 and Offset=-500 -Power Input: 3-6S LiPo The flight controller is powered through the G, V wires of the 8pin harness or G, V pads from the bottom aspect of the flight controller -5V Output: four teams of 5V output, three +5V pads and 1 BZ+ pad( used for Buzzer) on front aspect The whole recent load is 2A -9V Output: 1 organization of 9V output, one +9V pad on front side The whole current load is 3A -3 Output: Supported Soldering pad named &;3V3&; at the front height of the flight controller Designed for 3 enter receivers Up to 500mA latest load -4 Output: Supported Designed for radio receiver and GPS module even if the FC is powered through the USB port Up to 1A latest load -ESC Signal: M1 - M4 wires or soldering pads on backside facet -UART: 6 sets(UART1, UART2, UART3, UART4(Dedicated for Bluetooth connection)), UART5(Dedicated for ESC telemetry),UART6 -ESC Telemetry: UART R5(UART5); -I2C: Supported DA & CL pads on entrance aspect Used for magnetometer, sonar, etc; -Traditional Betaflight LED Pad: Supported 5V, G and LED pads on bottom of the entrance side Used for WS2812 LEDs controlled by way of the Betaflight firmware -Buzzer: BZ+ and BZ- pad used for 5V Buzzer; -BOOT Button: Supported Press and preserve BOOT button and power the FC on on the similar time will force the FC to go into DFU mode, this is for firmware flashing when the FC will get bricked -RSSI Input: Not Supported; -Smart Port / F: Not Supported; -Supported Flight Controller Firmware: BetaFlight(Default), INAV; -Firmware Target Name: SPEEDYBEEF405MINI; -Mounting: 20 x 20mm three hole diameter, Compatible with M2 and M3 screws/Silicone grommets -Dimension: 30(L) x 32(W) x 7(H)mm; -Weight: 9; ProductName: SpeedyBee 35A BLHeli_S Mini V2 4-in-1 ESC -Firmware: BLHeli_S J-H-40; -Continuous Current: 35A*4; -Burst Current: 45A(5seconds); -ESC Protocol: DSHOT300/600; -Power Input: 3-6S LiPo; -Power Output: VBAT(Battery voltage, used to power the flight controller); -Current Sensor: Support (Scale=250 Offset=-500); -Mounting: 20x20mm ∅3 gap size, well matched with M2 and M3 screws/Silicone grommets -Dimension: 35*35*5; -Weight: 7; Product Name: SpeedyBee F405 Mini BLS 35A 20x20 Stack Flight Controller: SpeedyBee F405 Min; ESC: SpeedyBee BLS 35A Mini V2 4-in-1 ESC; Bluetooth: Supported Used to connect with the SpeedyBee App for flight controller and ESC parameter configuration Please make sure the MSP switch on UART 4 is turned on and set to a baud rate of 115200, in any other case Bluetooth functionality will not be available WiFi: NOT Supported; Wireless FC Firmware Flashing: NOT Supported; Wireless Blackbox Dwonload & Analysis: NOT Supported; Power Input: 3-6S LiPo; Mounting: 20x20mm three gap size, Compatible with M2 and M3 screws/Silicone grommets; Dimension: 32mm(L)x35mm(W)x14(H); Weight: 13;

•
•
•
•
•
